This article tell you about creating your own local SVN repository in your GNU/Linux box.
Even though I personally like git, I like the SVN's idea of having all your code safe somewhere in a remote server!
I personally do a lot of coding, and several times I have lost my precious programs/codes due to some stupid mistakes I did or because I don't backup my code very often. Keeping a plain backup your code is a pain, having you to maintain several copies of them, based on their version.
Hence, several times I felt that, oh God, if at all I had my own SVN server somewhere?
So, today finally tried to create my own SVN server, and voila, in less than 5 minutes, my own SVN server was up and running! I never had thought that creating your own SVN server was a such easy task.
If you people are looking for the same, this article is for you!
Here is a step by step procedure to create your own SVN server.
- Install SVN package.
You need to have subversion package installed.
If you don't have it, install it using command
sudo apt-get install subversion
- Create a SVN repository.
Next step is to create a SVN repository. First decide where you want to store your repository data? I kept my SVN repository in my home directory, so that it also gets backed up with my home directory backup. So, You can also do the same or store your SVN repository in any other place of your choice.
Use following command to create your own SVN repository in your home directory.
svnadmin create ~/my_svn_repo
This command will create a directory named 'my_svn_repo in' your home directory, with SVN's repository data inside it.
If you want to store your SVN repository somewhere else, replace
'~/my_svn_repo'
with your selected directory path.
- Change the SVN configuration for repository access.
You need to configure the SVN to tell it about the read and write access to your repository.
For this goto 'conf' directory present inside your SVN repository directory.
cd ~/my_svn_repo/conf
now open the file named svnserve.conf
vi svnserve.conf
OR
gedit svnserve.conf
and edit the file.
un-comment following lines (remove # from the beginning of the line.)
anon-access = read
auth-access = write
These lines tell about the read and write access to your SVN repository. 'anon-access = read' means anonymous users can read your SVN data.
The possible values are 'read', 'write' and 'none'. The default value 'read' should be OK, as its a local repository. However, if your machine is in a network, you may want to change it to 'none' . ie;
anon-access = none
The second line 'auth-access = write' tells about the access rights of the authorized users. The default value of 'write' should be OK and it means authorized users can read/write back the data to the SVN repository.
Below are some possible configurations;
- The default configuration
# anonymous users can only read the repository
anon-access = read
# authenticated users can both read and write
auth-access = write
- Restricted configuration
# anonymous users aren't allowed
anon-access = none
# authenticated users can both read and write
auth-access = write
- Configure the Authorization.
un-comment following lines from the 'svnserve.conf' file opened in previous step.
password-db = passwd
This tells the SVN to read the user name and password from the file named 'passwd'.
- Setup the username and password.
Open the file name 'passwd' present inside 'conf' directory of your SVN repository directory.
Now un-comment the following lines.
harry = harryssecret
sally = sallyssecret
This line tells the authorized user's name ans password. You can also add your username and password to this list. like
raghu = mypassword
or use existing username and password such as 'sally' and 'billy', oops.. 'harry'.
- Start the daemon process.
Now enter following command to start the SVN daemon process.
svnserve -d --root ~/my_svn_repo/
that's it. you can now checkout your own local SVN repository like any other SVN repository. Just use following URL to access your local SVN repository.
svn://localhost
example:
svn co svn://localhost my_svn_works
Creating SVN directory structure:(optional)
Like the SVN's general convention, I recommend you to create 3 different directories. They are
trunk,
tags and
branches.
use following command to create them
svn mkdir branches tags trunk
now commit them to SVN.
svn commit
Making your SVN daemon process to start automatically with system.
The steps given above will start the daemon process, however if you restart your system, again you need to manually start the daemon process. Otherwise you can add a script to start the daemon process automatically with your system.
For this, You need to add a script to your /etc/init.d/
use following command to do it
echo "svnserve -d --root /home/raghunayak/my_svn_repo/" >> run_svnd && chmod +x run_svnd && sudo mv run_svnd /etc/init.d && sudo update-rc.d run_svnd defaults
In this command replace
'/home/raghunayak/my_svn_repo' with with your SVN repository path.
To remove this startup script enter following command.
sudo update-rc.d -f run_svnd remove && sudo rm /etc/init.d/run_svnd
If you like this article, please leave a comment..
